Description du produit
Negotiation
4/2-Gbps auto-negotiation
IOPS
200,000 initiator IOPS per port
Class of service
3
Topology
FC-AL, FC-AL2, point-to-point, switched fabric
Protocols
* FCP-3-SCSI
* FC-Tape (FCP-2)
PCI Express Interface
Compliance
* PCI Express Base Specification rev. 2.0
* PCI Bus Power Management Interface
Specification rev. 1.2
Physical and electrical
* IBM BladeCenter PCIe mezzanine slot connector
* StarPower link training
o Maximum x4 lanes for Gen2 rate
o Maximum x8 lanes for Gen1 rate
4/2-Gbps auto-negotiation
IOPS
200,000 initiator IOPS per port
Class of service
3
Topology
FC-AL, FC-AL2, point-to-point, switched fabric
Protocols
* FCP-3-SCSI
* FC-Tape (FCP-2)
PCI Express Interface
Compliance
* PCI Express Base Specification rev. 2.0
* PCI Bus Power Management Interface
Specification rev. 1.2
Physical and electrical
* IBM BladeCenter PCIe mezzanine slot connector
* StarPower link training
o Maximum x4 lanes for Gen2 rate
o Maximum x8 lanes for Gen1 rate
Caractéristiques
Marque | QLOGIC |
---|---|
Interface | Fibre Channel 4Gb/s |
Nombre de ports | 2 |
Facteur de forme | Exppress Module |
Normes | ANSI Fibre Channel: FC-PH-3, FC-PI-2, FC-FS, FC-AL-2, FC-GS-4, FC-FLA, FC-PLDA, FC-SP, FC-TAPE, FCP-2, and RFC 2625 (IP over FC) |
