Description du produit
Général
STANDARDS
ANSI Fibre Channel: FC-FS, FC-PH, FC-PI, FCP, FCP-2, FC-AL, FC-PLDA, FC-MI, FC-FLA, IETF IP over FC PCI-X 1.0a and PCI 2.3
Fibre Channel Class 2 and 3
PHP hot plug-hot swap
ARCHITECTURE
Emulex LightPulse® technology
2Gb/s or 1Gb/s FC Link
Quad Data Rate (QDR) SRAM Unified Data Buffer and Code Space memory
DRIVER SUPPORT
Windows Server 2003
Windows 2000
Windows NT
Linux
NetWare
Solaris
HP-UX
OEM custom drivers
HARDWARE ENVIRONMENTS
x86 and Intel® Itanium® processor family
SPARC and PowerPC PCI hardware platforms
3.3V signaling, 5V tolerant
32/64-bit 33/66MHz PCI
66/100/133MHz PCI-X
OPTICAL
data rates: 1.0625/2.125Gb/s (auto-detected)
optics: short wave lasers with LC type connector
cable: 50/125?m, up to 300 meters at 2Gb/s, 62.5/125?m, up to 150 meters at 2Gb/s
smart digital diagnostics interface supported
PHYSICAL DIMENSIONS
short low profile MD2 form factor card
167.64mm x 64.42mm (6.60 x 2.54)
standard bracket (low profile available)
STANDARDS
ANSI Fibre Channel: FC-FS, FC-PH, FC-PI, FCP, FCP-2, FC-AL, FC-PLDA, FC-MI, FC-FLA, IETF IP over FC PCI-X 1.0a and PCI 2.3
Fibre Channel Class 2 and 3
PHP hot plug-hot swap
ARCHITECTURE
Emulex LightPulse® technology
2Gb/s or 1Gb/s FC Link
Quad Data Rate (QDR) SRAM Unified Data Buffer and Code Space memory
DRIVER SUPPORT
Windows Server 2003
Windows 2000
Windows NT
Linux
NetWare
Solaris
HP-UX
OEM custom drivers
HARDWARE ENVIRONMENTS
x86 and Intel® Itanium® processor family
SPARC and PowerPC PCI hardware platforms
3.3V signaling, 5V tolerant
32/64-bit 33/66MHz PCI
66/100/133MHz PCI-X
OPTICAL
data rates: 1.0625/2.125Gb/s (auto-detected)
optics: short wave lasers with LC type connector
cable: 50/125?m, up to 300 meters at 2Gb/s, 62.5/125?m, up to 150 meters at 2Gb/s
smart digital diagnostics interface supported
PHYSICAL DIMENSIONS
short low profile MD2 form factor card
167.64mm x 64.42mm (6.60 x 2.54)
standard bracket (low profile available)
Caractéristiques
Marque | Emulex |
---|---|
Interface | Fibre Channel 2Gb/s |
Nombre de ports | 2 |
Facteur de forme | Low Profile MD2 (Demi-Hauteur Pleine Longueur) |
Normes | ANSI Fibre Channel: FC-PH-3, FC-PI-2, FC-FS, FC-AL-2, FC-GS-4, FC-FLA, FC-PLDA, FC-SP, FC-TAPE, FCP-2, and RFC 2625 (IP over FC) |
